Free customization plan, free factory inspection, and free quotation!
Item SpecificationsBucket capacity2.5-4.5M³ Rated load5000kgMachine weight17500±300kgDump clearance at maximum lift3100-3780mmReach at maximum lift1100-1220mmWheel base3300mmTread2250mmMax breakout fo
Product recommendation：
| Item | Specifications |
| Bucket capacity | 2.5-4.5M³ |
| Rated load | 5000kg |
| Machine weight | 17500±300kg |
| Dump clearance at maximum lift | 3100-3780mm |
| Reach at maximum lift | 1100-1220mm |
| Wheel base | 3300mm |
| Tread | 2250mm |
| Max breakout force | 175±5kn |
| Max horse power | 160±5kn |
| Hydraulic cycle time-raise | 6s |
| Total hydraulic cycle time | 10.5S |
| Min. turning radius over tyres | 5925±50mm |
| Articulation angle | 38° |
| Gradeability | 30° |
| Tyre size | 23.5-25-16PR |
| Overall machine dimension L×W×H | 8225×3016×3515mm |
| Engine | Weichai |
| Rated Power | 162Kw |
| Travel speed (Ⅰ-gear(F/R)) | 13/17Km/h |
| Ⅱ-gear(F) | 41Km/h |
